MAX691ACSE

Microprocessor supervisory circuit, SOP, MaxCap or SuperCap Compatible

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.70 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~0.70

PartNumber:: MAX691ACSE

Brand:: Maxim Integrated Products - Maxim | Pack: SOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. winona's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-05

From Other Seller

Part Number:MAX691ACSE
US $0.50 - 0.70
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The MAX691ACSE microprocessor (μP) supervisory circuit is pin-compatible upgrade to the MAX691. It improves performance with 30μA supply current, 200ms reset active delay on power-up, and 6ns chipenable propagation delay. Features include write protection of CMOS RAM or EEPROM, separate watchdog outputs, backup battery switchover, and a RESET output that is valid with VCC down to 1V. The MAX691ACSE has a 4.65V typical reset threshold voltage.

Parametrics

MAX691ACSE absolute maximum ratings: (1)Terminal Voltage (with respect to GND), VCC=-0.3V to +6V; (2)VBATT=-0.3V to +6V;(3)All Other Inputs: -0.3V to (VOUT + 0.3V); (4)Input Current, VCC Peak=1.0A, VCC Continuous=250mA, VBATT Peak=250mA,VBATT Continuous=25mA; (5)GND, BATT ON=100mA, All Other Outputs=25mA; (6)Continuous Power Dissipation (TA = +70℃), Plastic DIP (derate 10.53mW/℃ above +70℃)=842mW; (7)Narrow SO (derate 8.70mW/℃ above +70℃)=696mW; (8)Wide SO (derate 9.52mW/℃ above +70℃)=762mW; (9)CERDIP (derate 10.00mW/℃ above +70℃)=800mW; (10)Operating Temperature Ranges: 0v to +70v; (11)Storage Temperature Range: -65℃ to +160v; (12)Lead Temperature (soldering, 10sec):+300v.

Features

MAX691ACSE features: (1)200ms Power-OK/Reset Timeout Period; (2)1μA Standby Current, 30μA Operating Current; (3)On-Board Gating of Chip-Enable Signals 10ns Max Delay; (4)MaxCap or SuperCap Compatible; (5)Guaranteed Assertion to VCC = +1V; (6)Voltage Monitor for Power-Fail or Low-Battery Warning; (7)Power-Fail Accuracy Guaranteed to ±2% (MAX800L/M); (8)Available in 16-Pin Narrow SO and Plastic DIP Packages.
