DP8572AN

RTC, DIP, -0.5V to +7.0V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $12.00~15.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $12.00~15.00

PartNumber:: DP8572AN

Brand:: National Semiconductor - NS | Pack: DIP | D/C: 03+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. winona's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-07-04

From Other Seller

Part Number:DP8572AN
US $12.00 - 15.00
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
EKZE250ELL152MK25S

US $0.10 - 1.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The DP8572AN is a Real Time Clock (RTC). It is intended for use in microprocessor based systems where information is required for multi-tasking, data logging or general time of day/date information. The DP8572AN is implemented in low voltage silicon gate microCMOS technology to provide low standby power in battery back-up environments. The circuit’s architecture is such that it looks like a contiguous block of memory or I/O ports. The address space is organized as 2 software selectable pages of 32 bytes. The DP8572AN includes the Control Registers, the Clock Counters, the Alarm Compare RAM, and the Time Save RAM. Any of the RAM locations that are not being used for their intended purpose may be used as general purpose CMOS RAM.

Parametrics

DP8572AN absolute maximum ratings: (1)Supply Voltage (VCC): -0.5V to +7.0V; (2)DC Input Voltage (VIN): -0.5V to VCC + 0.5V; (3)DC Output Voltage (VOUT): -0.5V to VCC + 0.5V; (4)Storage Temperature Range: -65℃ to +150℃; (5)Power Dissipation (PD): 500 mW; (6)Lead Temperature (Soldering, 10 sec.): 260℃.

Features

DP8572AN features: (1)Full function real time clock/calendar: 12/24 hour mode timekeeping, Day of week and day of years counters, Four selectable oscillator frequencies, Parallel resonant oscillator; (2)Power fail features: Internal power supply switch to external battery, Power Supply Bus glitch protection, Automatic log of time into RAM at power failure; (3)On-chip interrupt structure: Periodic, alarm, and power fail interrupts; (4)Up to 44 bytes of CMOS RAM; (5)MIL-STD-883C compliant; (6)SMD Y5962-91641-01MJX (future).
