Product Summary

The DF06S is a Miniature Glass Passivated Single-Phase Surface Mount Bridge Rectifier. The DF06S is used in ac-to-dc bridge full wave rectification for SMPS, lighting ballaster, adapter, battery charger, home appliances, office equipment, and telecommunication applications.

Parametrics

DF06S absolute maximum ratings: (1)Device marking code: 600V; (2)Maximum RMS voltage, VRMS: 420V; (3)Maximum DC blocking voltage, VDC: 600V; (4)Maximum average forward output rectified current at TA = 40℃, IF(AV): 1.0 A; (5)Peak forward surge current single half sine-wave superimposed on rated load, IFSM: 50 A; (6)Rating for fusing (t<8.3 ms), I2t: 10 A2s; (7)Operating junction and storage temperature range, TJ, TSTG: - 55 to + 150℃.

Features

DF06S features: (1)UL recognition, file number E54214; (2)Ideal for automated placement; (3)High surge current capability; (4)Meets MSL level 1, per J-STD-020, LF maximum peak of 250℃; (5)Solder dip 260℃, 40 s; (6)Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC.

Diagrams

DF06S circuit

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DF06S
DF06S

Fairchild Semiconductor

Bridge Rectifiers 1.5A Bridge

Data Sheet

0-1: $0.23
1-25: $0.19
25-100: $0.17
100-250: $0.15
DF06S/45
DF06S/45

Vishay Semiconductors

Bridge Rectifiers 1.0 Amp 600 Volt

Data Sheet

Negotiable
DF06S_Q
DF06S_Q

Fairchild Semiconductor

Bridge Rectifiers 1.5A Bridge

Data Sheet

Negotiable
DF06SA
DF06SA

Other


Data Sheet

Negotiable
DF06SA-E3/45
DF06SA-E3/45

Vishay Semiconductors

Bridge Rectifiers 1.0 Amp 600 Volt 30 Amp IFSM

Data Sheet

0-1: $0.25
1-10: $0.22
10-100: $0.19
100-250: $0.17
DF06SA-E3/77
DF06SA-E3/77

Vishay Semiconductors

Bridge Rectifiers 1.0 Amp 600 Volt

Data Sheet

0-1: $0.26
1-10: $0.24
10-50: $0.22
50-100: $0.19
DF06S-E3/45
DF06S-E3/45

Vishay Semiconductors

Bridge Rectifiers 1.0 Amp 600 Volt

Data Sheet

0-1: $0.27
1-10: $0.23
10-100: $0.17
100-250: $0.15
DF06S-E3/77
DF06S-E3/77

Vishay Semiconductors

Bridge Rectifiers 1.0 Amp 600 Volt

Data Sheet

0-1: $0.25
1-10: $0.23
10-50: $0.21
50-100: $0.19
